DongGuan Mi Sung Mould Steel Co.,ltd
5 Years
| Ask Lasest Price | |
| Brand Name : | takford |
| Model Number : | P80 |
| Price : | USD 2-4/KG |
| Payment Terms : | L/C, T/T, Western Union |
| Supply Ability : | 1000 TONS PER MONTH |
| Delivery Time : | 10-20 DAYS |
For high precision mirror-polishing plastic mould or moulds of household appliance which requires high surface condition.
EF or Esr, Hot rolled or Forged, black surface or milling
Hardness:37-43HRC
Width:205-610mm Thickness:20-250mm
Low alloy precipitated hardening steel; good comprehensive mechanical properties,high hardenability, convenient heat treatmernt, good polishability. Also has good nitriding, electrical machining. welding and pattern etching performance.
| Foreign Grade | China Grade | C | Si | Mn | P | S | Cr | Mo | Ni | Others |
| --- | 10Ni3MnCuAl | 0.10-0.15 | 0.10-0.15 | 1.00-2.00 | ≤0.03 | ≤0.03 | ---- | 0.10-0.40 | 2.50-3.5 | Cu 0.70-1.50 Al 0.70-1.10 |
| P80 | ---- | 0.15 | 0.30 | 1.50 | --- | ---- | 0.30 | 0.30 | 3.00 | Cu 1.00 Al 1.00 |
|
|
